Product Overview
The LRS-350-24 24V 14.6A 350W Single Output Switching Power Supply for Industrial Automation is a Low Voltage Transformers product. It features high-efficiency 24v dc power solution: delivers stable 24v output with.
Key Features
- High-Efficiency 24V DC Power Solution: Delivers stable 24V output with 14.6A current capacity and 350W maximum power, achieving 88% conversion efficiency for energy-saving operation. Ideal for 24V industrial control systems, LED display arrays, and telecom equipment requiring reliable power distribution.
- Wide Input Voltage Range: Supports 85-264VAC universal input (47-63Hz) with built-in PFC function, compatible with global voltage standards. Features 150% peak load capacity for handling sudden power surges in automation equipment and production line applications.
- Advanced Protection & Safety: Integrated with over voltage/current/short-circuit protection and automatic recovery function. Certified with UL/IEC/EN 62368 safety standards, ensuring secure operation in commercial lighting systems and industrial machinery installations.
- Compact Industrial Design: Features 199*98*38mm metal housing with IP20 protection level and 1m flying lead output. Supports convection cooling with -30°C to +70°C operating temperature range for harsh environments like manufacturing plants and outdoor LED installations.
- Smart Power Management: Equipped with remote ON/OFF control and power good signal function. Includes 5-year warranty and complies with EMI Class B/EMS standards for interference-free operation in sensitive electronic systems and communication base stations.
Why Choose the LRS-350-24 24V 14.6A 350W Single Output Switching Power Supply for Industrial Automation
The LRS-350-24 24V 14.6A 350W Single Output Switching Power Supply for Industrial Automation offers high-efficiency 24v dc power solution: delivers stable 24v and wide input voltage range: supports 85-264vac universal input. These features make the LRS-350-24 24V 14.6A 350W Single Output Switching Power Supply for Industrial Automation a strong option in the Low Voltage Transformers category.
Best For
The LRS-350-24 24V 14.6A 350W Single Output Switching Power Supply for Industrial Automation is best suited for: 24V industrial control systems.
Quick Summary
The LRS-350-24 24V 14.6A 350W Single Output Switching Power Supply for Industrial Automation is a Low Voltage Transformers product by . Brand: GFZ. Product Dimensions: 8.47"D x 4.53"W x 1.18"H. Current Rating: 14.6 Amps. Specification Met: Cb(dekra) 3nd, Cb(ul) 2nd, E183223 Ul, Eac. Item Weight: 1.7 Pounds. Price: $46.86.
Product Specifications
| Specification | Details |
|---|---|
| Brand | GFZ |
| Product Dimensions | 8.47"D x 4.53"W x 1.18"H |
| Current Rating | 14.6 Amps |
| Specification Met | Cb(dekra) 3nd, Cb(ul) 2nd, E183223 Ul, Eac |
| Item Weight | 1.7 Pounds |
